Commercial sourcing scope
A PLC splitter quotation should connect the network topology to a measurable optical specification. Split ratio, package and connectorization alter both installation practice and the available PON loss budget.
Specify 1×N or 2×N topology, split ratio, bare-fiber or packaged construction, input and output fiber length, connector type and polish, wavelength range, maximum insertion loss, uniformity, polarization-dependent loss, return loss, directivity and operating environment.
Specification and selection table
| Decision item | What to confirm |
|---|---|
| 1×8 theoretical split | 9.03 dB before excess loss |
| 1×16 theoretical split | 12.04 dB before excess loss |
| 1×32 theoretical split | 15.05 dB before excess loss |
| 1×64 theoretical split | 18.06 dB before excess loss |
Standards and engineering interpretation
Use the project or operator specification to define test wavelength, connector reference method, maximum loss and report format. The test record should identify the device and individual output ports.
For broader technical context, review PLC splitter selection and our quality-assurance method.
Information to send for a quotation
- Application and installation environment
- Complete product construction or drawing reference
- Optical, mechanical and environmental limits
- Applicable standard, edition and customer-specific clauses
- Required test records and acceptance method
- Quantity, packaging, destination and delivery schedule
